BC-2F智能聲光報警裝置產品說明
產品概述：
BC-2F系列智能報警裝置是集警示音效與光學信號于一體的安全預警設備，采用模塊化結構設計，適用于工業設施、倉儲管理、智能樓宇等場景的安全警示需求。設備內置多頻段警示音調庫，配合高可見度光學組件，形成有效的視聽雙重警示效果。
核心功能特性：
-
復合警示模式：支持脈沖頻閃與旋轉光束兩種光效模式，適配不同環境的光線條件。聲效系統采用寬頻揚聲單元，提供85dB-110dB可調警示音壓，確保在復雜環境中有效傳遞警報信息。
-
環境適應性設計：整機采用工程級防護構造，內部電路系統配備過載保護和穩壓模塊。工作溫度范圍覆蓋-25℃至+60℃，滿足多數工業環境的溫控要求。表面處理工藝符合IP55防護等級，有效抵御粉塵侵入和水流潑濺。
-
電力適配方案：兼容100-240V交流電源與24V直流備用電源雙模式供電，內置智能電源管理系統，支持主備電源自動切換功能。典型工況下整機功耗低于15W，符合節能運行要求。
應用場景：
• 自動化產線設備異常預警
• 物流倉儲區域安全警示
• 智能建筑消防聯動系統
• 公共設施應急指示裝置
產品優勢：
三色LED光源模組采用光導管勻光技術，實現270度有效可視角度。金屬合金外殼經過陽極氧化處理，配合防震安裝支架，確保設備在振動環境中的穩定運行。維護界面采用卡扣式結構設計，便于日常清潔保養。
技術參數：
外形尺寸：Φ220×155mm（直徑×高度）
凈重：1.8kg±5%
音頻輸出：5種可編程警示音調
光效參數：紅藍雙色LED/7000mcd亮度
持續工作時長：≥20000小時
接線方式：三芯屏蔽電纜接入
BC-2F Intelligent Audible-Visual Alarm System
Product Overview:
The BC-2F series intelligent alarm device integrates acoustic alerts with visual signals, featuring modular design for industrial facilities, warehouse management, and smart building applications. Equipped with multi-frequency alert tones and high-visibility optical components, it delivers effective dual-mode warning functionality.
Key Features:
-
Multi-mode Operation: Offers pulse strobe and rotating beam lighting effects with adjustable 85dB-110dB acoustic output. The wide-range speaker ensures clear alert propagation in complex environments.
-
Environmental Durability: Engineered with industrial-grade protection, including overload protection and voltage stabilization. Operational in -25℃ to +60℃ environments with IP55-rated dust/water resistance.
-
Power Flexibility: Dual-mode power supply (100-240V AC/24V DC) with automatic switching capability. Energy-efficient design maintains power consumption below 15W during standard operation.
Application Scenarios:
• Automated production line anomaly alerts
• Logistics warehouse safety notifications
• Building fire control systems
• Public facility emergency indicators
Technical Advantages:
Tri-color LED modules with light-guide diffusion technology provide 270-degree visibility. Anodized aluminum alloy housing with anti-vibration brackets ensures stable performance. Tool-free maintenance access simplifies servicing.
Performance Specifications:
Dimensions: Φ220×155mm (Diameter×Height)
Net Weight: 1.8kg±5%
Audio Output: 5 programmable alert tones
Optical Output: Red/blue LEDs @7000mcd
Service Life: ≥20,000 hours
Connection: 3-core shielded cable interface
