R7-D料位開關
R7 - D料位開關產品介紹
中文介紹
R7 - D料位開關是一款高效、可靠的物料位置檢測設備，廣泛應用于工業生產中的固體物料存儲與輸送環節。其采用先進的傳感技術，能夠精準地檢測物料在容器中的位置，無論是粉末、顆粒還是塊狀物料，都能準確感知，為生產過程的自動化控制提供有力支持。
在設計上，R7 - D料位開關注重耐用性和適應性。它具備堅固的外殼，能夠抵御惡劣的工業環境，如粉塵、潮濕、高溫等常見工況，確保設備長期穩定運行。同時，其安裝方式靈活多樣，可適應不同形狀和大小的容器，無論是垂直安裝還是傾斜安裝，都能精準測量。
該料位開關操作簡便，用戶可以根據實際生產需求輕松設置檢測高度和靈敏度。其輸出信號穩定可靠，可直接與 PLC 等自動化控制系統對接，實現物料的自動補給、高位報警和低位報警等功能，有效避免物料溢出或缺料導致的生產中斷，提高生產效率，降低人工成本。
R7 - D料位開關以其卓越的性能和穩定的運行表現，成為了眾多工業企業物料管理的得力助手，助力企業實現生產過程的智能化與高效化。
English Introduction
The R7 - D level switch is an efficient and reliable material position detection device, widely used in the storage and transportation of solid materials in industrial production. It employs advanced sensing technology to accurately detect the position of materials in containers. Whether it is powder, granules, or lumps, it can sense them precisely, providing strong support for the automated control of the production process.
In terms of design, the R7 - D level switch focuses on durability and adaptability. It features a robust casing that can withstand harsh industrial environments, such as dust, humidity, and high temperatures, ensuring long - term stable operation of the equipment. At the same time, its installation methods are flexible and diverse, adaptable to containers of different shapes and sizes. Whether installed vertically or at an angle, it can measure accurately.
The level switch is easy to operate. Users can easily set the detection height and sensitivity according to actual production needs. Its output signal is stable and reliable, and it can be directly connected to automation control systems such as PLCs to achieve automatic material replenishment, high - level alarms, and low - level alarms. This effectively prevents production interruptions caused by material overflow or shortages, improving production efficiency and reducing labor costs.
With its outstanding performance and stable operation, the R7 - D level switch has become a valuable tool for material management in many industrial enterprises, helping them achieve intelligent and efficient production processes.
R7-D料位開關
技術特點
性強:應用于各種場合，飛灰、顆粒、粉體液體枯胭、導電和非導電物料。
抗粘附電路:來用抗粘附電路可以物料的粘附而產生虛假信號。
探頭可折式:探頭與控制器可分離，無電纜連接，安裝拆除不影洞進出科。
探頭耐高低溫:探頭適臺184260C的工作環境，還提供國資高溫探頭。
輸出實量大:采用容盤為10A .11的腿電器敏點輸出，并有狀態燈顯示工作狀態，0~ 30動科時功能貼片技術:使電路線路抗壙性更強，電路參數更穩定更可靠，
浪壓技術:提高了探頭的使用壓力，延長的使用壽命
技術參數
1.電源：220VAC/110VAC/24VAC/24VDC
2.觸點容量：250VAC/10A SPDT（單刀雙擲）
3.功率：4W
4.葉片轉速：1RPM（轉/分）
5.力矩：1.0kg×cm
6.物料比重：≥0.5g/cm3
7.工作溫度：-10℃-80℃（zui高可達400℃）
8.絕緣電阻：≥100MΩ
9.介電強度：1500V*1min
