JDB-2-3聲光報警器
JDB-2-3防爆靜電接地報警器產品介紹（中英文）
中文介紹：
JDB-2-3防爆靜電接地報警器是一款專為石油、化工、制藥等易燃易爆環境設計的靜電安全防護設備。該產品分為固定式（JDB-2）和移動式（JDB-3）兩種型號，適用于加油站卸油口、加氣站裝卸區、化工廠液態化工品卸車場地等場所。固定式采用3米接地線+5米靜電夾端線設計，適合固定作業場景；移動式配備雙靜電夾及5米長導線，便于移動作業。當檢測到接地回路電阻超過80Ω時，設備會觸發90分貝聲光報警，提醒人員及時檢查連接狀態，確保靜電有效釋放。產品采用環氧樹脂密封工藝，具備防腐、防水、防潮特性，內置鋰電池可支持長時間連續工作，無需頻繁更換電池。其破漆針采用特殊合金材質，能有效破除接觸面銹蝕，保障接地可靠性。125
English Introduction:
The JDB-2-3 Anti-static Grounding Alarm is designed for hazardous environments such as petroleum, chemical, and pharmaceutical industries. It includes two models: the fixed-type (JDB-2) with a 3m grounding wire + 5m clamp cable for stationary operations, and the mobile-type (JDB-3) featuring dual clamps with 5m cables for flexible use. When the circuit resistance exceeds 80Ω, the device triggers a 90dB audible and visual alarm to prompt immediate inspection. Encapsulated with epoxy resin, it offers corrosion resistance and waterproof performance. The built-in lithium battery ensures long-term operation without frequent replacement. Its alloy-coated piercing needles effectively break through surface rust for stable grounding. Suitable for fuel depots, paint factories, and alcohol production areas, it enhances operational safety during material transfer processes.3615
產品特點與適用場景（中英文）
中文特點：
該報警器采用超低功耗設計，靜態電流≤0.85mA，報警時≤3.95mA，可持續工作三年無需維護。固定式配備壁掛防雨箱體，移動式附帶橡膠底座，適應-10℃~50℃工作溫度范圍。其聲光報警功能通過集成電路實現穩定監測，無機械開關，支持24小時自動值守。特別適用于油漆廠、制藥廠等需靜電接地的場所，能快速響應接觸不良情況，避免靜電火花引發的安全隱患。2716
Key Features:
With an ultra-low power consumption design (static current ≤0.85mA), the alarm operates continuously for up to 3 years. The fixed version includes a wall-mounted rainproof casing, while the mobile version comes with rubber bases. It functions reliably within -10℃~50℃ and utilizes integrated circuits for real-time monitoring without manual switches. Ideal for environments like pharmaceutical plants and paint facilities, it instantly alerts users to poor contacts, mitigating fire risks caused by static sparks.51013
技術參數與用戶價值（中英文）
中文參數：
工作電流報警時為≤3.95mA，靜態≤0.85mA；報警音量達90dB（30cm距離檢測）；接地夾破漆壓力≥10N，確保強力接觸。設備主體尺寸為240×250×120mm（固定式），移動式線纜總長10米。休眠模式下8分鐘無操作自動進入節能狀態，重新連接后即刻喚醒。用戶可通過聲光提示直觀掌握接地狀態，簡化安全檢查流程。6715
Technical Specifications:
Operating current: ≤3.95mA (alarm mode) / ≤0.85mA (standby); sound intensity reaches 90dB at 30cm. The clamps provide over 10N piercing force for reliable contact. Dimensions: 240×250×120mm (fixed-type); mobile cables total 10m. An 8-minute idle time activates sleep mode, which resumes upon reconnection. Users benefit from intuitive alerts that streamline safety checks during hazardous material handling.136
JDB-2-3聲光報警器
|
接線方法
|
|
|
|
電源線 引入口(CABLE ENTRY)
|
|
|
|
|
|
1.使用防水接頭或者船舶用填料函
|
|
|
2.電源線 接入口:標準規格 : PF 1/2
|
|
|
3.引入口 PF 3/4 尺寸可以定做
|
|
|
接線方法
|
|
|
1.AC交流電源產品：不用分正負極,直接連接電源.
|
|
|
2.DC直流電源產品：黑色線端子連接在負極(-)。
|
|
|
3.為了更**的連接,電源線的端部使用冷壓接線端子“O"型"U"型
|
|
|
|
JDB-2-3聲光報警器
